Automatic pallet magazines for production lines

PALOMAT® Inline - electric

The pallet magazine, which is constructed 100% for your project, is the ideal component for stacking and destacking empty pallets in production lines

Save time, reduce installation and operating costs, and optimise your workflow by outsourcing with the electric PALOMAT® Inline – a user-friendly, flexible, and energy-efficient solution.

100% customised to your project

You save time on development, design, and production

100% electric

Flexible and thoroughly tested product

Why you should choose PALOMAT® Inline - electric

The electric PALOMAT® Inline can be easily connected to a standard industrial power outlet, making it highly flexible to position in any facility. With its low energy consumption, it also provides an energy-efficient solution that combines user-friendliness with reduced operating costs.



  • Customised 100% to your project – regardless of conveyor type, 4-way pallet type or pallet direction
  • Plugin solution – easy to implement in facilities of any size

  • Greener, energy-efficient operation
  • Future-ready – flexible and prepared to meet future production needs
  • Low maintenance – the electrical components require minimal servicing and operational monitoring
  • Equipped with a terminal box for external control
  • Complies with the current machinery directive



With our electric model, PALOMAT® Inline, you achieve an efficient, reliable, and economical production line while improving your project’s bottom line. Get one step closer to automated pallet handling. Outsource your next pallet magazine to the expert: PALOMAT®.



Get a offer!


Specifications

  • PALOMAT® Inline - electric



    Electric data
    Type Funktion Psc. I/O Power Consumption Power Consumption per unit

    SEW Eurodrive DRN63M2

    Lifting motor 2 Use frequency converter/VFD 1,1A - 0,25kW 2,2A - 0,5kW
    LINAK LA28 Gripper actuators - Activation signal 2 4 output 4A - 96W 8A - 192W
    LINAK LA28 Gripper actuators - Feedback signal 4 4 input
    SICK IME18-08BPSZC0S Inductive proximity sensors 6 6 input 20mA - 0,48W 120mA - 2,88W
    SICK VTE18-3F4712 Photoelectric sensors 2 2 input 30mA - 0,72W 60mA - 1,44W



    Max power consumption for lifting motors at 380VAC/3P: 2,2A - 0,5kW

    Max power consumption for gripper actuators at 24V DC:

    Max power consumption for sensors at 24V DC: 180mA - 4,32W





    Liftingkapacitet:

    500 kg

  • PALOMAT® Inline videos



    Watch videos















Pictures of PALOMAT® Inline



Pallet magazines in various models and production lines

Pallet magazin PALOMAT® Inline in stainless steel for stacking and destacking empty pallets in a production line



Pallet magazin PALOMAT® Inline handles empty pallets in a production line

Pallet magazin PALOMAT® Inline integrated into a production line

Pallet magazin PALOMAT® Inline where an AGV is handling the loading and onloading of empty pallets

Pallet magazin PALOMAT® Inline in stainless steel as a part of a production line



Pallet magazin PALOMAT® Inline handles plastic pallets in a production line



Pallet magazin PALOMAT® Inline with an adjustable side - which makes it possible to handle different pallet sizes in the same pallet magazine
